Features | Specification |
---|---|
Configuration | Active 2-Way |
Enclosure Type | Bass-Reflex Loudspeaker/Floor Monitor |
Total Power Capacity | 2100 W |
Amplifier Power Rating | LF: 1400 W Peak HF: 700 W Peak |
Amplifier Class | Class-D |
HF Driver | 1 x 1" / 25.4 mm Titanium Compression Driver |
HF Voice Coil | 1.75" / 44.45 mm |
LF Driver | 1 x 10" / 254 mm Woofer |
LF Voice Coil | 2.5" / 63.5 mm |
Frequency Response | 50 Hz to 20 kHz |
Maximum SPL | 130 dB (Peak) |
Coverage Angle | 100° H x 60° V |
Gain Range | 0 dB to +42 dB |
I/O Impedance | Combo XLR-1/4" Mic Input: 6 Kilohms (Balanced) Combo XLR-1/4" Line Input: 21 Kilohms (Balanced/Unbalanced) 1/8" / 3.5 mm Line Input: 13 Kilohms (Unbalanced) XLR Line Output: 150 Ohms |
Protections | RMS, Signal Limiter, Thermal |
Audio I/O | 2 x Combo XLR-1/4" TRS Female Balanced/Unbalanced Mic/Line Input 1 x XLR 3-Pin Male Balanced Line Thru/Output 1 x 1/8" / 3.5 mm TRS Female Unbalanced Line Input |
USB | 1 x USB-A (Service) |
Wireless Connectivity | Bluetooth |
Wireless Range | 328.1' / 100 m (Bluetooth) |
Crossover | High-Pass: 1600 Hz (Internal) |
EQ | Yes |
Parametric EQ | Yes |
Dynamic Processing | Compression, Soft Limiter |
Digital Signal Processing | FIR Filter, Venue Settings |
AC Input Power | Universal: 100 to 120 VAC, 60 Hz |
AC Power I/O | 1 x IEC Input (Locking) |
Power Consumption | 300 W |
Mounting | 2 x M10 Fly Point 1 x 1.38" / 35 mm Pole Socket (Bottom) |
Construction Material | Composite, Polypropylene, Stainless Steel Grille |
Dimensions | 22.5 x 13 x 12.2" / 571.5 x 330.2 x 309.9 mm |
Weight | 34.8 lb / 15.8 kg |
